Celsa 70030-2380-0500 AST 412 Current Transformer 600/5A 5VA Kl. 1

The Celsa AST 412 600/5A 5VA Kl. 1 current transformer attachment is designed for primary currents of 600 A and secondary currents of 5 A. It features a line feed-through opening measuring 41 x 41 mm with a diameter of 33 mm, suitable for various current conversion applications. Typical uses include integrating into AC converter systems, monitoring current loops, and enhancing electrical system efficiency.

Type	Current transformer attachment
Primary Current	600A
Accuracy Class	1
Calibrated	FALSE
Height opening	13-41mm
Line feed-through (H x W)	41 x 41 mm
Line feed-through (H)	41mm
Line feed-through (W)	41mm
Line feed-through diameter	33mm
Misc Attribute	AST 412 600/5A 5VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	33mm
Overcurrent limiting factor	FS 5
Rated primary current	600A
Rated secondary apparent power	5VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	13-41mm
With contact protection	TRUE
With copper rail	FALSE
