Celsa 70030-1044-1000 AST 315 Current Transformer 750/5A 10VA Compact

The Celsa AST 315 750/5A 10VA Kl. 1 current transformer is designed for primary currents of 750 A and outputs a secondary current of 5 A. With a line feed-through of 33 x 33 mm and a diameter of 28 mm, this attachment is well-suited for integration in electrical measurement and monitoring systems. Common applications include use in electrical substations and distribution systems for accurate current measurement and control.

Type	Current transformer attachment
Primary Current	750A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 750/5A 10VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	750A
Rated secondary apparent power	10VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
