Celsa 70030-1041 AST 315 Current Transformer 80A/5A, Compact Design

Celsa's AST 315 80/5A 1.25VA Kl. 1 current transformer attachment is designed for a primary current of 80 A and a secondary current of 5 A. It features a line feed-through measuring 33 x 33 mm with a diameter of 28 mm. Ideal for current measurement and monitoring in electrical systems, this product can be used in various industrial applications.

Type	Current transformer attachment
Primary Current	80A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 80/5A 1.25VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	80A
Rated secondary apparent power	125VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
