Celsa 70030-1040 AST 315 Current Transformer 75/5A Compact Design

The Celsa AST 315 75/5A 1.25VA Kl. 1 is a high-precision current transformer attachment, manufactured by Celsa, designed to convert a primary current of 75 A to a secondary current of 5 A. With its compact dimensions and specific line feed-through diameter, this Celsa current transformer is suitable for integration into systems requiring accurate current measurement and monitoring. It is typically used in electrical applications involving current loops and ac conversion.

Type	Current transformer attachment
Primary Current	75A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 75/5A 1.25VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	75A
Rated secondary apparent power	125VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
