Celsa 70030-1029-0150 AST 315 Current Transformer 200/1A Kl. 1 Compact

The Celsa AST 315 200/1A 1.5VA Kl. 1 current transformer attachment is designed for primary currents of 200 A and converts them to a secondary current of 1 A. Featuring a line feed-through of 33 x 33 mm and a diameter of 28 mm, this attachment is suitable for accurate current measurement and monitoring applications. It is typically used in electrical power systems for reliable current sensing and protection purposes.

Type	Current transformer attachment
Primary Current	200A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 200/1A 1.5VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	200A
Rated secondary apparent power	15VA
Rated secondary current	1A
Secondary connection	Screw connection
Secondary current	1A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
