Celsa 70030-1015-0500 AST 315 Current Transformer 400/5A 5VA Kl. 1

The Celsa AST 315 400/5A 5VA Kl. 1 current transformer attachment is designed for converting a primary current of 400 A to a secondary current of 5 A. This device, with line feed-through dimensions of 33 x 33 mm and a feed-through diameter of 28 mm, is ideal for use in ac converters and current loop applications. Celsa 70030-1015-0500 is typically used in electrical measurement and monitoring systems

Type	Current transformer attachment
Primary Current	400A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 400/5A 5VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	400A
Rated secondary apparent power	5VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
