Celsa 70017-1464 EAST315 Current Transformer 250/5A 5VA PTB Approved

Celsa's EAST315 250/5A 5VA Kl. 0.5 is a current transformer designed for converting a primary current of 250 A to a secondary current of 5 A. It features a line feed-through of 33 x 33 mm dimensions with a diameter of 28 mm. This transformer is suitable for use in electrical load monitoring and energy management systems.

Type	Current transformer attachment
Primary Current	250A
Accuracy Class	0.5
Calibrated	TRUE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	EAST315 250/5A 5VA Kl. 0.5
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	250A
Rated secondary apparent power	5VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
