Bourns SRR6038-100Y Choke SMD 10 µH 38 mΩ 2 A

Bourns SRR6038-100Y is a high-performance Surface Mount Device (SMD) choke designed for applications requiring an efficient and compact solution for electromagnetic interference suppression. This component has a nominal inductance of 10 µH and exhibits a low direct current resistance (DCR) of 38 mO, allowing for effective current handling up to 2 A. The compact form factor of this choke makes it well-suited for use in power management systems, telecommunications, and automotive electronics where space conservation and high efficiency are critical. The SRR6038-100Y utilises an advanced composite core material to provide excellent thermal stability and reliability.

Type	Choke
Resistance	38mΩ
Content	1
Dimensions	(L x W x H) 6.8 x 6.8 x 3.8 mm
Height	3.8mm
Inductance (L)	10µH
Length	6.8mm
Nominal Current	2A
Product Type	Choke
Quality Q at MHz	2.52MHz
Tolerance ±	30%
Width	6.8mm
