Bourns 4609X-101-103Lf Resistor Ladder 10KΩ Tht Sip 9 0.2 W 1 Piece

Bourns 4609X-101-103LF is a resistor ladder designed for precision applications requiring reliable resistance configurations. This component belongs to the category of resistor arrays and networks, characterised by its 10 kO resistance value and a power rating of 0.2 watts. It is constructed in a through-hole SIP-9 package, ideal for simplified board design and robust physical connectivity. Engineers often utilise the Bourns 4609X-101-103LF in applications such as digital-to-analogue conversion, signal processing, and adjustable filtering circuits, where consistent performance and endurance are paramount. Its configuration as a ladder network makes it especially suitable for compact circuit layouts, ensuring systematic resistance scaling with minimal footprint.

Type	Resistor ladder
Resistance	10kO
Number of Resistor	8
Power Rating	0.2W
Tolerance	2%
Network Type	Commoned
Content	1
Dimensions	(L x W x H) 22.81 x 2.49 x 5.08 mm
Height	5.08mm
Length	22.81mm
Maximum Temperature	125°C
Temperature Coefficient	100ppm/°C
Width	2.49mm
