Bourns 3314J-1-203E Cermet trimmer 0.25 W 20 kΩ 210° 240° single unit

Bourns 3314J-1-203E is a high-precision cermet trimmer potentiometer designed for reliable and accurate resistive adjustment in electronic circuits. Also known by its alternate reference, 2996263, this single unit product features a resistance value of 20 kO, a power rating of 0.25 watts, and an adjustable rotation range of 210° to 240°. The trimmer's robust construction ensures stability and longevity, making it suitable for applications such as calibration, signal conditioning, and tuning oscillators in various electronic devices. Its compact design and precise adjustment capabilities facilitate its integration into densely populated printed circuit boards where space and precision are critical.

Resistance	20kΩ
Power Rating	0.25W
Connection	SMT
Content	1
Cross Section	2.35mm
Dimensions	(L x W x H) 4.5 x 4.5 x 2.55 mm
Electrical Angle	210°
Height	2.55mm
Length	4.5mm
Maximum Temperature	125°C
Mechanical Angle	240°
Minimum Temperature	-55°C
No. of rotations	1
Operation type	top
Product Type	Cermet trimmer
Temperature Coefficient	100ppm/K
Tolerance ±	20%
Width	4.5mm
