Bourns 3314J-1-103E Cermet trimmer 0.25 W 10 kΩ 210 ° 240 ° 1 piece

Bourns 3314J-1-103E is a cermet trimmer potentiometer, identified by part number 2996259. This precision device is rated at 0.25 watts and has a resistance value of 10 kO, offering a rotational adjustment angle between 210° and 240°. It is designed for fine-tuning and calibration in various electronic circuits, making it an ideal choice for settings where precise voltage, current, or signal adjustments are required. The cermet element provides stability and reliability, making it suitable for use in applications such as communication equipment, instrumentation, and industrial control systems.

Type	Cermet Trimmer
Resistance	10kO
Tolerance	20%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	1
Pitch	2.3 x 4mm
Connection	SMT
Content	1
Cross Section	2.35mm
Dimensions	(L x W x H) 4.5 x 4.5 x 2.55 mm
Electrical Angle	210°
Height	2.55mm
Length	4.5mm
Maximum Temperature	125°C
Mechanical Angle	240°
Minimum Temperature	-55°C
Operation type	top
Temperature Coefficient	100ppm/K
Tolerance ±	20%
Width	4.5mm
