Bourns 3266W-1-504LF Cermet trimmer linear 0.25 W 500 kΩ 4320° 1 pc

Bourns 3266W-1-504LF is designed for precision adjustment in circuits, featuring a high-quality cermet material. This trimmer potentiometer offers a resistance of 500 kO and can handle a power rating of 0.25 watts. It boasts a linear adjustment spanning 4320 degrees, ensuring fine-tuned control for intricate circuit configurations. The Bourns 3266W-1-504LF is particularly suited for use in applications such as tuning circuits, sensor adjustments, and calibration in measurement devices. Referred to alternately as 2996161, this component is engineered to provide reliable performance in a wide range of electronic systems.

Type	Cermet Trimmer
Resistance	500kΩ
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	Solder pins
Content	1
Cross Section	2.54mm
Dimensions	(L x W x H) 6.71 x 4.5 x 7.24 mm
Electrical Angle	4320°
Height	7.24mm
Length	6.71mm
Max. temperature	125°C
Maximum Temperature	125°C
Min. temperature	-55°C
Minimum Operating Temperature	-55°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.5mm
