Bourns 3266W-1-254LF Cermet trimmer linear 0.25W 250kΩ 4320° 1pc

Bourns 3266W-1-254LF is a precision cermet trimmer potentiometer designed for linear adjustment, offering a resistance value of 250 kO and a power rating of 0.25 watts. This component features a rotational travel of 4320°, making it well-suited for applications requiring fine tuning and precise control, such as in calibration circuits, sensor adjustments, and feedback loop configuration. The robust construction of the 3266W-1-254LF ensures long-term reliability and stability which is essential for demanding engineering environments. As an alternative description, this product is also identified by the part number 2996156, ensuring easy cross-referencing in technical documentation.

Type	Cermet Trimmer
Resistance	250kO
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	Solder pins
Content	1
Cross Section	2.54mm
Dimensions	(L x W x H) 6.71 x 4.5 x 7.24 mm
Electrical Angle	4320°
Height	7.24mm
Length	6.71mm
Maximum Temperature	125°C
Minimum Temperature	-55°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.5mm
