Bourns 3266W-1-105LF Trimmer Cermet Linear 0.25 W 1 MΩ 4320° 1 pc

Bourns 3266W-1-105LF is a precision trimmer potentiometer, also known under the alternate description as product code 2996151. This robust component features a cermet element with a resistance value of 1 MO, offering precise linear adjustments over a total mechanical travel of 4320 degrees. Rated at 0.25 watts, this device is designed for use in environments where accurate resistance tuning is crucial, such as in calibration of test equipment, adjustment of circuit offset values, and fine-tuning audio electronics. Its compact design and durable materials ensure reliable operation in various electronic applications, making it a suitable choice for engineers seeking a dependable solution for fine electrical control.

Resistance	1MΩ
Power Rating	0.25W
Connection	Solder pins
Content	1
Cross Section	2.54mm
Dimensions	(L x W x H) 6.71 x 4.5 x 7.24 mm
Electrical Angle	4320°
Height	7.24mm
Length	6.71mm
Maximum Temperature	125°C
Minimum Temperature	-55°C
No. of rotations	12
Operation type	top
Product Type	Cermet trimmer
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.5mm
