Bourns 3266P-1-502LF 3266P Cermet trimmer linear 0.25W 5kΩ 4320° 1pc

Bourns 3266P-1-502LF is a trimmer potentiometer from the 3266P series, known for its reliable performance in precise resistance adjustment applications. This cermet trimmer provides a resistance of 5kO, with a power rating of 0.25W and a rotational range of 4320 degrees, which ensures fine-tuned control and accuracy in electrical circuits. As offering, also referenced as 2996145, this component is typically used in applications such as calibration circuits, signal processing adjustments, and other scenarios where repeatable resistance settings are critical. Its compact design and durable construction make it suitable for integration into printed circuit boards where space and reliability are key considerations.

Resistance	5kΩ
Power Rating	0.25W
Connection	Solder pins
Content	1
Cross Section	2.54mm
Dimensions	(L x W x H) 6.71 x 6.78 x 4.5 mm
Electrical Angle	4320°
Height	4.5mm
Length	6.71mm
Maximum Temperature	125°C
Minimum Temperature	-55°C
No. of rotations	12
Operation type	side
Product Type	Cermet trimmer
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	6.78mm
