Bourns 3224W-1-502E Cermet trimmer linear 0.25 W 5 kΩ 4320 ° 1 pc

Bourns 3224W-1-502E is a precision cermet trimmer potentiometer designed for reliable linear performance. This specific model boasts a resistance of 5 kO, power rating of 0.25 W, and a rotational life of 4320 cycles, which makes it suitable for precise adjustments in various electrical and electronic circuits. Known under the alternate description 2996140 - Bourns 3224W-1-502E, it commonly finds application in calibration procedures, sensor adjustments, and frequency modulation tasks where exact resistance tuning is required. This single-turn trimmer consists of a durable cermet element that ensures enhanced stability and performance in demanding operational environments.

Type	Cermet Trimmer
Resistance	5kΩ
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	2.5mm
Dimensions	(L x W x H) 4.8 x 3.5 x 5.3 mm
Electrical Angle	4320°
Height	5.3mm
Length	4.8mm
Max. temperature	150°C
Maximum Temperature	150°C
Min. temperature	-65°C
Minimum Operating Temperature	-65°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	3.5mm
