Bourns 3224W-1-501E Linear trimmer 0.25 W Cermet 500 Ohm 4320° 1 pcs

Bourns 3224W-1-501E is a precision-engineered linear trimmer that offers a resistance of 500 ohms with a power rating of 0.25 watts, designed for high accuracy and reliability. This component utilises a cermet element, which provides stability and endurance in varying environments, making it suitable for applications requiring precise adjustment and tuning. The trimmer features a full-scale rotation of 4320 degrees, allowing for fine control in electronic circuit calibration. Commonly employed in instrumentation, telecommunications, and industrial control systems, the Bourns 3224W-1-501E ensures consistent performance across demanding operating conditions. It is recognised by the alternate description 2996139 in relevant engineering documentation.

Resistance	500Ω
Power Rating	0.25W
Connection	SMT
Content	1
Cross Section	2.5mm
Dimensions	(L x W x H) 4.8 x 3.5 x 5.3 mm
Electrical Angle	4320°
Height	5.3mm
Length	4.8mm
Maximum Temperature	150°C
Minimum Temperature	-65°C
No. of rotations	12
Operation type	top
Product Type	Cermet trimmer
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	3.5mm
