Bourns 3224W-1-101E Cermet trimmer linear 0.25 W 100 Ω 4320° 1 pc

Bourns 3224W-1-101E is a high-precision cermet trimmer potentiometer designed for applications requiring reliable and adjustable resistance. This product, also recognised by the alternate description 2996132, features a resistance value of 100 ohms and supports a power rating of 0.25 watts. With a total rotational angle of 4320 degrees, it enables fine adjustments, ideal for calibration in electronic circuits. Typical uses include tuning circuits and setting gain levels in audio equipment, sensors, or other precision devices where minor resistance adjustment is crucial. Its robust design ensures excellent stability and longevity, making it a preferred choice among engineers for demanding applications.

Type	Cermet Trimmer
Resistance	100Ω
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	2.5mm
Dimensions	(L x W x H) 4.8 x 3.5 x 5.3 mm
Electrical Angle	4320°
Height	5.3mm
Length	4.8mm
Max. temperature	150°C
Maximum Temperature	150°C
Min. temperature	-65°C
Minimum Operating Temperature	-65°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	3.5mm
