Bourns 3224J-1-503E Cermet trimmer linear 0.25 W 50 kΩ 4320 ° 1 pc

Bourns 3224J-1-503E, also known under the alternate description 2996131, is a cermet trimmer featuring a linear resistance characteristic with a resistance value of 50 kO. This component is capable of handling a power rating of 0.25 W and is capable of precise adjustments over its full rotational range of 4320 degrees. Engineered for reliability and stability, the Bourns 3224J-1-503E is commonly used in circuits requiring fine-tuning of resistance, such as calibration circuits, sensor adjustments, and control systems. Its robust design and accurate performance make it an essential component in both consumer electronics and industrial applications.

Type	Cermet Trimmer
Resistance	50kΩ
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Side
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	4.8mm
Dimensions	(L x W x H) 4.8 x 4.6 x 3.71 mm
Electrical Angle	4320°
Height	3.71mm
Length	4.8mm
Max. temperature	150°C
Maximum Temperature	150°C
Min. temperature	-65°C
Minimum Operating Temperature	-65°C
Operation type	side
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.6mm
