Bourns 3224J-1-102E Cermet trimmer linear 0.25 W 1 kΩ 4320 ° 1 pc

Bourns 3224J-1-102E is a high-quality cermet trimmer potentiometer designed to provide precision and reliable performance in various electronic circuits. Offering a resistance value of 1 kO, this linear trimmer pot supports a power rating of 0.25 W and features an adjustment range of 4320°, making it suitable for applications requiring fine-tuning and calibration, such as instrumentation and feedback control systems. This component, also referred to by the identifier 2996124, is manufactured by Bourns and is ideal for integration into both commercial and industrial settings where stability and precision are paramount. Its compact design and robust construction ensure optimal functionality in a wide range of environmental conditions, making it a versatile choice for engineers seeking dependable trimming solutions.

Type	Cermet Trimmer
Resistance	1kΩ
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Side
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	4.8mm
Dimensions	(L x W x H) 4.8 x 4.6 x 3.71 mm
Electrical Angle	4320°
Height	3.71mm
Length	4.8mm
Maximum Temperature	150°C
Minimum Temperature	-65°C
Operation type	side
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.6mm
