Block SIM300 Safety Transformer 230V AC 2x12V 300VA 12.5A Short Circuit Safe

Block's SIM 300 is a safety transformer with a primary voltage of 230 V AC and dual secondary outputs of 12 V AC, designed with a power capacity of 300 VA and a current rating of 12.5 A. Its robust construction makes it suitable for universal applications, including automation and power supply systems. The transformer, weighing 4.9 kg, is ideal for use in environments where mains voltage needs to be safely transformed to a lower voltage for various operational needs.

Type	Safety transformer
Primary Voltages	230V
Power Rating	300VA
Current Rating	12.5A
Connection	Screw terminal
Design type	Encapsulated, cast in insulated casing
Efficiency	91%
Fitting method	Hole opening in terminal connection box
Frequency	50 - 60Hz
Input voltage (number x voltage)	1 x 230 V AC
Insulation class	A
Max. ambient temperature	+40°C
Mounting Type	Screw fastening
Number of Inputs	1
Number of Outputs	2
Output voltage (number x voltage)	2 x 12 V AC
Protection Class	II
Standards	As per IEC 61558-2-6, DIN EN 61558-2-6, VDE 0570 Part 2-6
Test mark	VDE
