Bernstein Ltd. 6085167108 BI2-SU1Z RIW Limit Switch 240V AC 10A Lever IP65

The Bernstein 6085167108 BI2-SU1Z RIW is a limit switch designed for use with 240 V AC and 10 A with a lever mechanism. It is manufactured by Bernstein AG and features IP65 protection, ensuring durability in harsh environments. This switch is typically used in industrial applications for monitoring moving parts, providing precise position detection.

Type	Limit switch
Alignment of the control element	Roller cam straight
Ambient temperature during operating	-30 - 80°C
Coating housing	N/A
Connection	Screws
Construction type housing	Other
Contact opening	Quick-action switching element
Degree of protection (IP)	IP65
Degree of protection (NEMA)	4X
Depth	32mm
Diameter sensor	N/Amm
Dim	(W x H x D) 58 x 50 x 32 mm (Casing)
Dim. (add. text)	Casing
Explosion safety category for dust	None
Explosion safety category for gas	None
Forced opening	true
Functions	momentary
Height	50mm
Height of sensor	32mm
Housing Material	Plastic
IP Rating	IP65
Length of sensor	73mm
Material	Plastic
Misc Attribute	BI2-SU1Z RIW
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	1
Number of contacts as normally open contact	1
Number of safety auxiliary contacts	1
Operation type	Lever
Output electronic	false
Rated operation current Ie at AC-15, 125 V	N/AA
Rated operation current Ie at AC-15, 230 V	3A
Rated operation current Ie at AC-15, 24 V	N/AA
Rated operation current Ie at DC-13, 125 V	N/AA
Rated operation current Ie at DC-13, 230 V	N/AA
Rated operation current Ie at DC-13, 24 V	N/AA
Suitable for safety functions	true
Switching current (max.)	10A
Switching function	Quick-break switch
Switching function latching	false
Switching Voltage	240V AC
Thread Size	M16
Type of control element	Roller cam
Type of electric connection	Cable entry metrical
Type of interface	None
Type of interface for safety communication	None
Width	58mm
Width sensor	58mm
With status indication	false
