The B + B Thermo-Technik pressure sensor (Model: 0550 1281-007) measures air pressure from 0 bar up to 10 bar. It features a compact design with a cable dimension of 27 mm in diameter and 53 mm in length, suitable for various industrial applications. Typical uses include monitoring and controlling pressure in pneumatic systems and other pressure-sensitive environments.
Type Pressure sensor
(Ø) 27mm
Burst load 25bar
Connector Cable, 3-core
Dim (Ø x L) 27 mm x 53 mm
IP rating IP67
Length 53mm
Max. temperature 80°C
Min. temperature -20°C
Misc Attribute 1 0550 1281-007
Misc Attribute 2 Round
Model Relative pressure
Output signal (max.) 20mA
Output signal (min.) 4mA
Outputs Voltage (analogue)
Pressure reading range 0 bar up to 10 bar
Pressure reading range (max.) 10bar
Pressure reading range (min.) 0bar
Weight 182g
