ATE Electronics RB50/7-8R2-J Power Resistor 50W 8.2Ohm Axial Wirewound

ATE Electronics RB50/7-8R2-J is a robust power resistor designed for applications requiring high impedance. This axial wirewound resistor offers a resistance value of 8.2 ohms and is rated for a power dissipation of 50 watts, making it suitable for use in demanding electrical circuits where reliable performance is necessary. Its construction utilises resistance wire to ensure consistent operation, and it is ideal for applications such as power management systems, industrial machinery, and audio equipment, where dissipating and controlling excess heat and voltage is crucial. The RB50/7-8R2-J is part of ATE Electronics' high power resistor range, known for durability and precision in environments with significant power loads.

Type	High power Resistor
Resistance	8.2Ω
Tolerance	5%
Power Rating	50W
Content	1
Dimensions	(L x W x H) 91 x 29.2 x 16 mm
Height	16mm
Insulation Resistance	10000MΩ
Length	91mm
Max. temperature	250°C
Maximum Temperature	250°C
Min. temperature	-55°C
Minimum Operating Temperature	-55°C
Temperature Coefficient	50ppm
Threshold Voltage	1250
Width	29.2mm
