ATE Electronics RB50/7-8R0-J Power Resistor 8 Ohms 50W 5% Axial Lead

ATE Electronics RB50/7-8R0-J is a high-power resistor with a resistance value of 8 ohms and a power rating of 50 watts, engineered for applications requiring precision and robustness. This axial lead resistor is constructed using high-grade resistance wire, providing 5% tolerance to accommodate high-impedance demands. It is designed to perform consistently in circuits where dissipating large amounts of power is essential, extending its utility in power supply units, motor drives, and other industrial electrical systems. The ATE Electronics RB50/7-8R0-J is tailored for engineers seeking reliable performance in high-temperature and high-current environments, offering durability and efficiency in various electronic applications.

Type	High power Resistor
Resistance	8Ω
Tolerance	5%
Power Rating	50W
Content	1
Dimensions	(L x W x H) 91 x 29.2 x 16 mm
Height	16mm
Insulation Resistance	10000MΩ
Length	91mm
Max. temperature	250°C
Maximum Temperature	250°C
Min. temperature	-55°C
Minimum Operating Temperature	-55°C
Temperature Coefficient	50ppm
Threshold Voltage	1250
Width	29.2mm
