ATE Electronics RB50/7-10R-J Power Resistors High Power Durable 10 Ohm

ATE Electronics RB50/7-10R-J is a high power resistor designed for applications requiring robust performance and reliability. This component, characterised by its 10 ohm resistance, utilises a specialised resistance wire configuration to ensure effective heat dissipation and impedance stability in demanding environments. The RB50/7-10R-J is engineered for high power applications, making it ideal for use in industrial power supply circuits, load testing, and other scenarios where durable resistance under high thermal loads is crucial. Its construction and materials support high durability, ensuring consistent operation over prolonged usage periods.

Type	High power Resistor
Resistance	10Ω
Tolerance	5%
Power Rating	50W
Content	1
Dimensions	(L x W x H) 91 x 29.2 x 16 mm
Height	16mm
Insulation Resistance	10000MΩ
Length	91mm
Max. temperature	250°C
Maximum Temperature	250°C
Min. temperature	-55°C
Minimum Operating Temperature	-55°C
Temperature Coefficient	50ppm
Threshold Voltage	1250
Width	29.2mm
