ATE Electronics RB25/7-6R8-J Power Resistors 6.8 Ohm 25W Axial Leaded

ATE Electronics RB25/7-6R8-J power resistors are designed for high-power applications requiring robust performance and reliability. Featuring a resistance of 6.8 ohms, these axial leaded resistors can handle power dissipation up to 25 watts, making them ideal for situations where efficient heat management and high power handling are crucial. Constructed with precision resistance wire, they offer consistent high impedance, making them suitable for use in power electronics, current limiting applications, and motor control circuits. The RB25/7-6R8-J is equally suited for both industrial and consumer electronics where stability and performance are priorities.

Type	High power Resistor
Resistance	6.8Ω
Tolerance	5%
Power Rating	25W
Content	1
Dimensions	(L x W x H) 69 x 27.7 x 14 mm
Height	14mm
Insulation Resistance	10000MΩ
Length	69mm
Max. temperature	250°C
Maximum Temperature	250°C
Min. temperature	-55°C
Minimum Operating Temperature	-55°C
Temperature Coefficient	50ppm
Threshold Voltage	550
Width	27.7mm
