ATE Electronics RB101-0R12-J-1 High Power Resistor 0.12Ohm 100W 5%

ATE Electronics RB101-0R12-J-1 is a high power resistor specifically designed for demanding applications, boasting a resistance of 0.12 ohms with a power rating of 100 watts and a tolerance of 5%. This wire-wound resistor, identified by the EAN 2050000107054, features a robust construction with dimensions of 65.5 x 27 x 26 mm and is axially leaded for secure integration into circuits. Its design maximises performance in environments requiring high current handling and precision resistive applications, making it an ideal choice for use in power supplies, motor drives, and industrial control systems. As a passive component, it is essential for managing energy distribution and reducing current fluctuations, ensuring reliable operation in various electronics systems.

Type	High power Resistor
Resistance	0.12Ω
Tolerance	5%
Power Rating	100W
Content	1
Design Type	Wire
Dimensions	(L x W x H) 65.5 x 27 x 26 mm
Height	26mm
Length	65.5mm
Maximum Temperature	+250°C
Min. temperature	-55°C
Width	27mm
