APEM Q22F5AYXXSY220E LED Indicator Light Yellow 230V AC 1250mcd

The APEM Q22F5AYXXSY220E LED indicator light is manufactured by APEM and offers a yellow light output with a brightness of 1250 mcd. It operates at 230 V AC and 6.0 V, making it suitable for both high and low voltage applications. Typically used for status indication and signalling in industrial panels and equipment, this LED light ensures durability and efficiency.

Type	LED indicator light
Lamp/Lens Colour	Yellow
(Ø)	25mm
Connection	Open end cable
Dimensions	(Ø x L) 25 mm x 22.5 mm
Forward Voltage U(F)	6.0V
Front panel thickness	10mm
Head height	2.5mm
Head Ø	25mm
IP Rating	Actuator side: IP67/Connection side: IP00
Length	22.5mm
Lifespan	100000h
Light intensity I(V)	1250mcd
Material	Aluminium/PVC
Material properties	anodised
Max. operating voltage	253V
Maximum Temperature	85°C
Min. operating voltage	207V
Min. temperature	-40°C
Misc Attribute	Q22 F5 AYXXSY220E
Mounting depth	22mm
Operating Current	3mA
Radiation Angle	30°
Recess Diameter	22mm
Shape	Also
