The Aim-TTi QPX1200SP is a laboratory dc power supply with a maximum
total output power of 1200W and is suited to both bench-top and system
applications. The Aim-TTi QPX1200SP adds full digital remote control
using USB, RS-232, LAN and GPIB interfaces and includes an analog remote
control.
The QPX1200S is a different type of laboratory power supply designed to meet
the need for flexibility in the choice of voltage and current.
A conventional
PSU has a fixed current limit giving a power capability that reduces directly
with the output voltage. The design of the Aim-TTi QPX1200SP enables
higher currents to be generated at lower voltages within an overall power limit
envelope. Each output can provide three times the current of a conventional PSU
of the same maximum voltage and power (see power curve).
To meet a wide variety of needs, the Aim-TTi QPX1200SP adds a
comprehensive array of digital bus interfaces. RS-232, USB, GPIB and LAN
(Ethernet) with LXI support are all provided as standard. Each of the digital
bus interfaces provides full control of voltage, current, output on/off and
set-up, plus read-back of voltage, current and status. The interfaces are at
ground potential and are opto-isolated from the output terminals. The GPIB
interface is compliant with IEEE-488.1 and IEEE-488.2. Currently GPIB remains
the most widely used interface for system applications.
- PowerFlex design with 1200W maximum power
- Wide range of voltage/current combinations
- Up to 60V and up to 50A within a power envelope
- Linear final regulation provides very low output noise and fast transient
response
- Setting by direct numeric entry or by spin wheel
- High setting resolution of 1mV in up to 60V
- Multiple non-volatile setting memories
- Variable OVP and OCP trips
- Low resistance and power calculation
- Analog control interfaces for voltage and current
- Bench or rack mounting with front and rear terminals
- GPIB, RS-232, USB & LAN (LXI) interfaces
- Manufacturer's part no. Aim-TTi
QPX1200SP
Not recommended for use as a battery charger.
| Number of Outputs |
1 |
| Output Voltage Min. |
0V |
| Output Voltage Max. |
60V |
| Output Current Min. |
0A |
| Output Current Max. |
50A |
| Power Rating |
1200W |
| Supply Voltage Range |
110 / 240V |
| Temperature Range |
+5 to +40°C |
