Weipu SP2113/P5 SP21 Round Connector Plug 5 Pins Waterproof UV Resistant

Image Representative of Range

Weipu SP2113/P5 SP21 Round Connector Plug 5 Pins Waterproof UV Resistant

Weipu
Standard range
Order Code:

13-5356

Brand: Weipu MPN: SP2113 / P 5 EAN-13: 2050001515209
Qty Unit Price (Ex VAT)
1+ £4.38
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
73 in stock, despatched in 4 working days

The Weipu SP2113/P 5 is a robust bullet connector plug with five pins, designed for reliable electrical connections in demanding environments. Part of the SP21 series, it is ideal for outdoor and industrial applications due to its durable construction. This connector is often used in equipment requiring secure and waterproof connections, such as lighting and automation systems.
Type Bullet connector
AWG 11
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, mount
Contact material Gold plated
Cross-section range 4.17 mm² (max)
IP rating IP68
max. cross section 4.17mm²
Max. temperature +105°C
Min. temperature -65°C
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 50A
Nominal current - rounded value 50A
Nominal voltage 230V
Number of pins 5
Pin diameter 3
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 5
