Weipu SP2112S9 SP21 Socket 9 Pin UV Resistant Waterproof Screw Lock

The Weipu SP2112/S 9 bullet connector socket is a built-in, round connector from the SP21 series with a total of 9 pins. Manufactured by Weipu, it offers robust connectivity ideal for outdoor or industrial applications. This connector is typically used in demanding environments, such as marine equipment or industrial machinery.

Type	Socket, built-in
Number of Contacts	9
Connector Size	29 mm dia
Gender	Socket
Case Material	PPS
Connection	Soldering
Connection Angle	180°
Contact Material	Gold plated
Cross-section range	0.758 mm² (max)
Current Rating	16A
IP Rating	IP68
max. cross section	0.758mm²
Mounting Hole Diameter	21mm
Nominal Voltage	400V
Series	SP21
Termination	Screw-type locking
Wire Gauge (AWG)	18
