Weipu SP2112 S7 SP21 Socket 7 Pins Waterproof UV-Resistant Connector

Image Representative of Range

Weipu SP2112 S7 SP21 Socket 7 Pins Waterproof UV-Resistant Connector

Weipu
Standard range
Order Code:

13-5351

Brand: Weipu MPN: SP2112 / S 7 EAN-13: 2050001515148
Qty Unit Price (Ex VAT)
1+ £5.09
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
51 in stock, despatched in 4 working days

The Weipu SP2112/S 7 bullet connector is a robust, built-in socket with a total of 7 pins, part of the SP21 series. Manufactured by Weipu, this round connector offers reliable performance in demanding environments. It is typically used in industrial applications that require secure and waterproof electrical connections.
Type Bullet connector
AWG 14
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, built-in
Contact material Gold plated
Cross-section range 2 mm² (max)
IP rating IP68
max. cross section 2mm²
Max. temperature +100°C
Min. temperature -40°C
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 16A
Nominal current - rounded value 16A
Nominal voltage 400V
Number of pins 7
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 7
