Weipu SP2112/P7 SP21 Connector 7-Pin Plug UV Resistant Waterproof

Image Representative of Range

Weipu SP2112/P7 SP21 Connector 7-Pin Plug UV Resistant Waterproof

Weipu
Standard range
Order Code:

13-5341

Brand: Weipu MPN: SP2112 / P 7 EAN-13: 2050001515056
Qty Unit Price (Ex VAT)
1+ £5.09
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
29 in stock, despatched in 4 working days

The Weipu SP2112/P7 bullet connector is a robust plug mount with a total of seven pins, belonging to the SP21 series of round connectors. Manufactured by Weipu, this connector is known for its durability and reliability in various industrial and outdoor applications. Typically used in marine, LED lighting, and machinery control systems, it ensures secure electrical connections in harsh environments.
Type Bullet connector
AWG 14
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, mount
Contact material Gold plated
Cross-section range 2 mm² (max)
IP rating IP68
max. cross section 2mm²
Max. temperature +80°C
Min. temperature -25°C
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 17.5A
Nominal current - rounded value 17.5A
Nominal voltage 500V
Number of pins 7
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 7
