Weipu SP2112/P3 SP21 Connector Plug 3-Pin Bullet Mount UV Resistant

Image Representative of Range

Weipu SP2112/P3 SP21 Connector Plug 3-Pin Bullet Mount UV Resistant

Weipu
Standard range
Order Code:

13-5337

Brand: Weipu MPN: SP2112 / P 3 EAN-13: 2050001515001
Qty Unit Price (Ex VAT)
1+ £4.38
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
142 in stock, despatched in 4 working days

The Weipu SP2112 / P 3 is a bullet connector plug with a mount designed for secure and reliable connections, featuring three pins in the SP21 series of round connectors. Manufactured by Weipu, this component is ideal for demanding applications requiring robust and weatherproof connectivity, such as outdoor lighting and industrial equipment. Its durable construction ensures it is suited for both commercial and industrial environments.
Type Bullet connector
AWG 11
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, mount
Contact material Gold plated
Cross-section range 4.17 mm² (max)
IP rating IP68
max. cross section 4.17mm²
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 13A
Nominal current - rounded value 13A
Nominal voltage 200V
Number of pins 3
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 3
