Weipu SP2111/S5 SP21 Bullet Connector Socket 5 Pins UV Resistant

Image Representative of Range

Weipu SP2111/S5 SP21 Bullet Connector Socket 5 Pins UV Resistant

Weipu
Standard range
Order Code:

13-5330

Brand: Weipu MPN: SP2111 / S 5 EAN-13: 2050001514936
Qty Unit Price (Ex VAT)
1+ £4.74
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
98 in stock, despatched in 4 working days

The Weipu SP2111/S 5 bullet connector is a straight socket with five pins, belonging to the SP21 series of round connectors. Manufactured by Weipu, it is designed for reliable electrical connections in various industrial and outdoor applications. This connector is typically used for secure and efficient power or signal transmission.
Type Bullet connector
AWG 11
Cable Ø (max.) 12mm
Cable Ø range 7 - 12 mm
Cable Ø up to 7mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, straight
Contact material Gold plated
Cross-section range 4.17 mm² (max)
IP rating IP68
max. cross section 4.17mm²
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute Weipu Connector
Nominal current 13A
Nominal current - rounded value 13A
Nominal voltage 200V
Number of pins 5
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 5
