Weipu SP2111/S3I SP21 Socket 3 Pins Straight Bullet Water Resistant

Image Representative of Range

Weipu SP2111/S3I SP21 Socket 3 Pins Straight Bullet Water Resistant

Weipu
Standard range
Order Code:

13-5328

Brand: Weipu MPN: SP2111 / S 3 I EAN-13: 2050001514912
Qty Unit Price (Ex VAT)
1+ £4.71
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
94 in stock, despatched in 4 working days

The Weipu SP2111/S 3 I bullet connector is a straight socket with three pins from the SP21 series of round connectors. Manufactured by Weipu, this connector is designed for reliable electrical connections in a variety of settings. It is typically used in industrial, automotive, and outdoor applications due to its robust construction and secure connection features.
Type Bullet connector
AWG 11
Cable Ø (max.) 7mm
Cable Ø range 4 - 7 mm
Cable Ø up to 4mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, straight
Contact material Gold plated
Cross-section range 4.17 mm² (max)
IP rating IP68
max. cross section 4.17mm²
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute Weipu Connector
Nominal current 13A
Nominal current - rounded value 13A
Nominal voltage 200V
Number of pins 3
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 3
