Weipu SP2111/S 9 II SP21 Bullet Connector Socket 9 Pins UV Water Resistant

Image Representative of Range

Weipu SP2111/S 9 II SP21 Bullet Connector Socket 9 Pins UV Water Resistant

Weipu
Standard range
Order Code:

13-5334

Brand: Weipu MPN: SP2111 / S 9 II EAN-13: 2050001514974
Qty Unit Price (Ex VAT)
1+ £5.43
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
84 in stock, despatched in 4 working days

Manufactured by Weipu, the SP2111 / S 9 II bullet connector features a straight socket design with a total of 9 pins. Part of the SP21 series, this round connector is known for its reliability and durability. It is typically used in applications requiring secure and compact electrical connections, such as in industrial and outdoor environments.
Type Bullet connector
AWG 18
Cable Ø (max.) 12mm
Cable Ø range 7 - 12 mm
Cable Ø up to 7mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, straight
Contact material Gold plated
Cross-section range 0.758 mm² (max)
IP rating IP68
max. cross section 0.758mm²
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute Weipu Connector
Nominal current 13A
Nominal current - rounded value 13A
Nominal voltage 500V
Number of pins 9
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 9
