Weipu SP2111/P5II SP21 Bullet Connector Plug Straight 5 Pins UV Resistant

Image Representative of Range

Weipu SP2111/P5II SP21 Bullet Connector Plug Straight 5 Pins UV Resistant

Weipu
Standard range
Order Code:

13-5321

Brand: Weipu MPN: SP2111 / P 5 II EAN-13: 2050001514844
Qty Unit Price (Ex VAT)
1+ £4.74
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
32 in stock, despatched in 4 working days

Manufactured by Weipu, the SP2111 / P 5 II is a straight bullet connector with 5 pins. Part of the SP21 series of round connectors, it offers reliable connectivity in various industrial and outdoor applications. The robust design makes it suitable for use in harsh environments.
Type Bullet connector
AWG 11
Cable Ø (max.) 12mm
Cable Ø range 7 - 12 mm
Cable Ø up to 7mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, straight
Contact material Gold plated
Cross-section range 4.17 mm² (max)
IP rating IP68
max. cross section 4.17mm²
Misc Attribute Weipu Connector
Nominal current 30A
Nominal current - rounded value 30A
Nominal voltage 500V AC
Number of pins 5
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 5
