Weipu SF1213/P2 SF12 Bullet Connector Straight 2-Pin Push-Pull Lock

The Weipu SF1213/P2 is a straight bullet connector plug with two pins, part of the SF12 series, used for secure electrical connections. Manufactured by Weipu, it is suitable for applications requiring reliable and compact round connectors. Its design makes it ideal for industrial and electronic equipment interfacing.

Type	Plug, straight
Number of Contacts	2
Connector Size	18 mm dia
Gender	Plug
Case Material	Brass, chrome plated
Connection	Soldering
Connection Angle	180°
Contact Material	Brass gold plated
Cross-section range	0.785 mm² (max)
Current Rating	7A
IP Rating	IP67
max. cross section	0.785mm²
Maximum Temperature	+85°C
Min. temperature	-40°C
Nominal Voltage	250V
Number of pins	2
Series	SF12
Termination	Push-Pull
Wire Gauge (AWG)	14
