Weipu SF1210/P5 II SF12 Bullet Connector Plug 5 Pins Push-Pull Lock

The Weipu SF1210/P5 II is a straight bullet connector plug with 5 pins, part of the SF12 series of round connectors. Manufactured by Weipu, this component is designed for reliable electrical connections in various electronic devices and applications. It is commonly used in industrial and commercial settings where secure and efficient wiring is required.

Type	Plug, straight
Number of Contacts	5
Connector Size	18 mm dia
Gender	Plug
Cable Ø (max.)	8mm
Cable Ø range	5 - 8mm
Cable Ø up to	5mm
Case Material	Brass, chrome plated
Connection	Soldering
Connection Angle	180°
Contact Material	Brass gold plated
Cross-section range	0.758 mm² (max)
Current Rating	5A
IP Rating	IP67
max. cross section	0.758mm²
Maximum Temperature	+70°C
Min. temperature	-20°C
Nominal Voltage	60V
Number of pins	5
Series	SF12
Termination	Push-Pull
Wire Gauge (AWG)	18
