| Type |
Metal body |
| Basic material |
Stainless steel 1.4301 |
| Colour |
Stainless steel |
| Corner model |
false |
| Couplable |
true |
| Declaration of Conformatiy No. (DoC |
DE PS2650 220428 |
| Degree of protection (IP) |
IP66 |
| Depth |
150 |
| Depth (inches) |
5.9055 inch |
| ECLASS 14.0 |
27-18-01-01 |
| ECLASS 15.0 |
27-18-01-01 |
| EMC-version |
false |
| Enclosure attachment |
Installation through the |
| ETIM 10.0 |
EC000261 |
| ETIM 8.0 |
EC000261 |
| ETIM 9.0 |
EC000261 |
| Flange plate |
Yes |
| Floor standing wall model |
false |
| Freestanding |
false |
| Gland plates |
Bottom |
| GTIN (EAN) |
4064675855767 |
| GTIN (EAN) 4008190850234 |
Depth: 20 mm, Basic material: Steel, silver |
| GTIN (EAN) 4008190850241 |
Depth: 30 mm, Basic material: Steel, silver |
| GTIN (EAN) 4008190857851 |
Depth: 15 mm, Basic material: Steel, silver |
| GTIN (EAN) 4050118063820 |
8.5 mm, Depth: 8.5 mm, Basic material: Steel, galvanized, galvanic |
| GTIN (EAN) 4050118753196 |
13.6 mm, Depth: 13.6 mm, Basic material: Stainless steel, rust-proof, |
| GTIN (EAN) 4064675275695 |
mm, Depth: 10.5 mm, Basic material: Steel, untreated, silver |
| GTIN (EAN) 4064675425168 |
240 mm, Depth: 1.5 mm, Basic material: Sheet steel, galvanized, |
| GTIN (EAN) 4064675425267 |
240 mm, Depth: 1.5 mm, Basic material: Stainless steel 1.4301 |
| GTIN (EAN) 4064675425359 |
Depth: 20 mm, Basic material: Stainless steel 1.4404, silver |
| GTIN (EAN) 4064675425366 |
Width: 171 mm, Depth: 16.5 mm, Basic material: Stainless steel |
| GTIN (EAN) 4064675425632 |
Width: 141 mm, Depth: 16.5 mm, Basic material: Stainless steel |
| Height |
300 |
| Height (inches) |
11.811 inch |
| housing rear wall |
after wall mounting using |
| Impact resistance |
10 J version standard |
| Impact strength |
IK09 |
| Intermediate mounting |
false |
| Lid attachment |
Quarter-turn fastener with |
| LVD) |
001ISS01 |
| M20 |
14 |
| Material |
Stainless steel |
| Material quality |
Stainless steel 304 (V2A) |
| Material thickness of cover |
1.5mm |
| Material thickness of enclosure |
1.5mm |
| Material thickness of flange |
3mm |
| Mounting plate depth-adjustable |
false |
| Net weight |
5487.18g |
| Note: protection class |
IP protection is only given |
| Number of doors |
1 |
| Number of locks |
1 |
| Operating Temperature |
-40 °C...85°C |
| Operating temperature, max. |
85°C |
| Operating temperature, min. |
-40°C |
| Pitched roof |
false |
| Pole fastening |
false |
| Protection degree |
IP66 |
| RAL-number |
7001 |
| REACH SVHC |
No SVHC above 0.1 wt% |
| ROHS |
Conform |
| RoHS Compliance Status |
Compliant without exemption |
| Seal material |
Chloroprene |
| Silicone |
No |
| Suitable for metrical mounting |
true |
| Suitable for outdoor set-up |
true |
| Suitable for wall built-in |
true |
| Suitable for wall mounting |
true |
| Surface finish |
untreated |
| Surface finishing |
Untreated |
| Version |
Klippon EBi QL (Essential Box industrial - Quarter |
| WDU 10 / ZDU 10 |
1x20 |
| WDU 2,5 / ZDU 2,5 / IDU 2,5 |
2x40 |
| WDU 35 / ZDU 35 |
1x12 |
| WDU 4 / ZDU 4 |
2x33 |
| WDU 6 / ZDU 6 |
2x25 |
| Width |
300 |
| Width (inches) |
11.811 inch |
| With glazed door |
false |
| With mounting plate |
false |
| With rear door |
false |
| With ventilation door |
false |
