| Type |
Metal body |
| Basic material |
Stainless steel 1.4301 |
| Colour |
Stainless steel |
| Corner model |
false |
| Couplable |
true |
| Declaration of Conformatiy No. (DoC |
DE PS2650 220428 |
| Degree of protection (IP) |
IP66 |
| Depth |
200 |
| Depth (inches) |
7.874 inch |
| ECLASS 14.0 |
27-18-01-01 |
| ECLASS 15.0 |
27-18-01-01 |
| EMC-version |
false |
| Enclosure attachment |
Installation through the |
| ETIM 10.0 |
EC000261 |
| ETIM 8.0 |
EC000261 |
| ETIM 9.0 |
EC000261 |
| Flange plate |
Yes |
| Floor standing wall model |
false |
| Freestanding |
false |
| Gland plates |
Bottom |
| GTIN (EAN) |
4064675855675 |
| GTIN (EAN) 4008190850234 |
Depth: 20 mm, Basic material: Steel, silver |
| GTIN (EAN) 4008190850241 |
Depth: 30 mm, Basic material: Steel, silver |
| GTIN (EAN) 4008190857851 |
Depth: 15 mm, Basic material: Steel, silver |
| GTIN (EAN) 4050118063820 |
8.5 mm, Depth: 8.5 mm, Basic material: Steel, galvanized, galvanic |
| GTIN (EAN) 4050118753196 |
13.6 mm, Depth: 13.6 mm, Basic material: Stainless steel, rust-proof, |
| GTIN (EAN) 4050118896381 |
thickness (A): 1.2mm |
| GTIN (EAN) 4064675275695 |
mm, Depth: 10.5 mm, Basic material: Steel, untreated, silver |
| GTIN (EAN) 4064675425182 |
340 mm, Depth: 1.5 mm, Basic material: Sheet steel, galvanized, |
| GTIN (EAN) 4064675425281 |
340 mm, Depth: 1.5 mm, Basic material: Stainless steel 1.4301 |
| GTIN (EAN) 4064675425359 |
Depth: 20 mm, Basic material: Stainless steel 1.4404, silver |
| GTIN (EAN) 4064675425366 |
Width: 171 mm, Depth: 16.5 mm, Basic material: Stainless steel |
| GTIN (EAN) 4064675425632 |
Width: 141 mm, Depth: 16.5 mm, Basic material: Stainless steel |
| GTIN (EAN) 4064675425649 |
Depth: 20 mm, Basic material: Stainless steel 1.4404, silver |
| GTIN (EAN) 4064675425656 |
Depth: 20 mm, Basic material: Stainless steel 1.4404, silver |
| Height |
400 |
| Height (inches) |
15.748 inch |
| housing rear wall |
after wall mounting using |
| Impact resistance |
10 J version standard |
| Impact strength |
IK09 |
| Intermediate mounting |
false |
| Lid attachment |
M5 hexagonal screw with |
| LVD) |
001ISS01 |
| M25 |
24 |
| M40 |
10 |
| M50 |
4 |
| M63 |
3 |
| Material |
Stainless steel |
| Material quality |
Stainless steel 304 (V2A) |
| Material thickness of cover |
1.5mm |
| Material thickness of enclosure |
1.5mm |
| Material thickness of flange |
3mm |
| Mounting plate depth-adjustable |
false |
| Net weight |
9515.05g |
| Note: protection class |
IP protection is only given |
| Number of doors |
1 |
| Number of locks |
2 |
| Operating Temperature |
-40 °C...85°C |
| Operating temperature, max. |
85°C |
| Operating temperature, min. |
-40°C |
| Pitched roof |
false |
| Pole fastening |
false |
| Protection degree |
IP66 |
| RAL-number |
7001 |
| REACH SVHC |
No SVHC above 0.1 wt% |
| ROHS |
Conform |
| RoHS Compliance Status |
Compliant without exemption |
| Seal material |
Chloroprene |
| Silicone |
No |
| Suitable for metrical mounting |
true |
| Suitable for outdoor set-up |
true |
| Suitable for wall built-in |
true |
| Suitable for wall mounting |
true |
| Surface finish |
untreated |
| Surface finishing |
Untreated |
| Version |
Klippon EBi HS (Essential Box industrial - Hinged |
| WDU 10 / ZDU 10 |
2x30 |
| WDU 16 / ZDU 16 |
2x24 |
| WDU 2,5 / ZDU 2,5 / IDU 2,5 |
3x59 |
| WDU 4 / ZDU 4 |
3x49 |
| WDU 6 / ZDU 6 |
2x37 |
| Width |
400 |
| Width (inches) |
15.748 inch |
| With glazed door |
false |
| With mounting plate |
false |
| With rear door |
false |
| With ventilation door |
false |
