W & P Products 635-06-2-00 Pin Strip 2mm Spacing 6 Pins 2 Rows

Image Representative of Range

W & P Products 635-06-2-00 Pin Strip 2mm Spacing 6 Pins 2 Rows

W & P Products
Order Code:

10-9610

Brand: W & P Products MPN: 635-06-2-00 EAN-13: 2050001142856
Qty Unit Price (Ex VAT)
10+ £0.597
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
265 in stock, despatched in 4 working days

The W & P Products 635-06-2-00 pin strip features a contact spacing of 2 mm with a total of 6 pins arranged in 2 rows. This component is commonly used in electronic and electrical applications for connecting circuits and components. With its precise pin spacing, it is ideal for compact and efficient circuit board designs.
Type Pin strip
Number of Rows 2
Case Material Thermoplastic material
Connection Print
Connector Type Pin strip, right angle
Contact Material Copper alloy
Contact surface Gold plated
CS 2mm
Dim (L x W x H) 8.5 x 13.2 x 8.5 mm
Factory colour Black
Height 8.5mm
Insulation Material Thermoplastic material
Insulation Resistance 5 x 108Ω
Length 8.5mm
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 2 Angled
Nominal Current 1A
Nominal current (details) 1A
Nominal Voltage 125V AC
Nominal voltage (details) 250V AC
Pins 2 x 3 mm
Pins per row 3
Temperature Range -40 - +105°C
Total number of pins 6
Width 13.2mm
