W & P Products 257-008-2-50-00-6 SIL Socket 2x4 Rows Precision Round Pins

Image Representative of Range

W & P Products 257-008-2-50-00-6 SIL Socket 2x4 Rows Precision Round Pins

W & P Products
Order Code:

10-9587

Brand: W & P Products MPN: 257-008-2-50-00-6 EAN-13: 2050001574589
Qty Unit Price (Ex VAT)
10+ £0.636
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
64 in stock, despatched in 4 working days

W & P Products manufactures the SIL socket with precision engineering, featuring two rows and four pins per row. This receptacle, model number 257-008-2-50-00-6, ensures reliable connections in electronic assemblies. It is typically used in circuit board applications requiring precise and secure socket connections.
Case Material Thermoplastic material
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector Type Power strip, straight
Contact Material Copper alloy
Contact surface Tin plated
CS 2mm
Dim (L x W x H) 8.00 x 7.40 x 4.20 mm
Dimensions L x B x H 8 x 4.2 x 7.4 mm
Factory colour Black
Height 4.20mm
Industrial packaging No
Length 8.00mm
Max. temperature +125°C
Min. temperature -55°C
Nominal Current 3A
Nominal current - rounded value 3A
Nominal Voltage 150V DC
Number of Rows 2
Pin length (PCB) 3.20mm
Pin Ø 0.40mm
Pin shape Circular
Pins per row 4
Separable No
Socket depth 3.50mm
Total number of pins 8
Type Receptacles (precision)
Width 7.40mm
