W & P Products 154-004-2-50-00 Precision Socket Connector 3A 2x2 Pins

Image Representative of Range

W & P Products 154-004-2-50-00 Precision Socket Connector 3A 2x2 Pins

W & P Products
Standard range
Order Code:

10-9559

Brand: W & P Products MPN: 154-004-2-50-00 EAN-13: 2050001143426
Qty Unit Price (Ex VAT)
1+ £0.617
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

W & P Products manufactures the 154-004-2-50-00 precision socket connector, featuring 2 x 2 pins and a nominal current of 3 A. These precision receptacles are suitable for robust electronic connections in various electrical and electronic applications. Ideal for use in circuit boards, they ensure secure and reliable connectivity.
Case material Thermoplastic material
Connection Print
Connector orientation Parallel (to the PCB)
Connector type Power strip, right angle
Contact material Copper alloy
Contact surface Tin plated
CS 2.54mm
Dim (L x W x H) 10.84 x 8.38 x 5.08 mm
Factory colour Black
Height 5.08mm
Industrial packaging No
Insulation resistance
> 1010Ω
Length 10.84mm
Manufacturer part # 154-004-2-50-00
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute 1 154-004-2-50-00
Misc Attribute 2 Angled
No. of rows 2
Nominal current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage 150V DC
Pin length (PCB) 3.30mm
Pin length (receptacle) 2.40mm
Pin Ø 0.60mm
Pin shape Circular
Pins 2 x 2
Pins per row 2
RoHS-compliant Yes
Separable No
Socket depth 5.80mm
Temperature range -55 - +125°C
Total number of pins 4
Type Receptacles (precision)
Width 8.38mm
