The W & P Products 154-002-1-50-00 Precision Socket Connector features 1 x 2 pins and is designed for a nominal current of 3 A. Manufactured by W & P Products, this precision receptacle is ideal for applications requiring reliable electrical connections. Typical uses include electronic devices and equipment where precise and secure connectivity is essential.
| Case material |
Thermoplastic material |
| Connection |
Print |
| Connector orientation |
Parallel (to the PCB) |
| Connector type |
Power strip, right angle |
| Contact material |
Copper alloy |
| Contact surface |
Tin plated |
| CS |
2.54mm |
| Dim |
(L x W x H) 8.30 x 5.84 x 5.08 mm |
| Factory colour |
Black |
| Height |
5.08mm |
| Industrial packaging |
No |
| Insulation resistance |
> 1010Ω |
| Length |
8.30mm |
| Manufacturer part # |
154-002-1-50-00 |
| Max. temperature |
+125°C |
| Min. temperature |
-55°C |
| Misc Attribute 1 |
154-002-1-50-00 |
| Misc Attribute 2 |
Angled |
| No. of rows |
1 |
| Nominal current |
3A |
| Nominal current - rounded value |
3A |
| Nominal current (details) |
3A |
| Nominal voltage |
150V DC |
| Pin length (PCB) |
3.30mm |
| Pin length (receptacle) |
2.40mm |
| Pin Ø |
0.60mm |
| Pin shape |
Circular |
| Pins |
1 x 2 |
| Pins per row |
2 |
| RoHS-compliant |
Yes |
| Separable |
No |
| Socket depth |
5.80mm |
| Temperature Range |
-55 - +125°C |
| Total number of pins |
2 |
| Type |
Receptacles (precision) |
| Width |
5.84mm |
