W & P Products 153PF-040-1-50-00 SIL Socket 1 Row, 40 Pins, Precision Fit

W & P Products manufactures the SIL socket (precision) with 1 row and 40 pins per row, identified as part number 153PF-040-1-50-00. This precision receptacle is suitable for applications requiring reliable and accurate connections. Typical uses include electronic circuit boards where stability and precise pin alignment are critical.

No. of Rows	1
No. of Ways	40
Case Material	Thermoplastic material
Connection	Print
Connector orientation	Perpendicular (to the PCB)
Connector Type	Power strip, straight
Contact Finish	Tin plated
CS	2.54mm
Dim	(L x W x H) 101.60 x 9.80 x 2.54 mm
Dimensions	L x B x H 101.6 x 2.54 x 9.8 mm
Factory colour	Black
Height	2.54mm
Industrial packaging	No
Length	101.60mm
Maximum Temperature	+125°C
Min. temperature	-55°C
Nominal Current	3A
Nominal current - rounded value	3A
Pin length (PCB)	2.80mm
Pins per row	40
Separable	No
Socket depth	6.10mm
Type	Receptacles (precision)
Width	9.80mm
