W & P Products 153PF-002-1-50-00 SIL Socket 1 Row 2 Pins 0.65-0.85mm Use

Image Representative of Range

W & P Products 153PF-002-1-50-00 SIL Socket 1 Row 2 Pins 0.65-0.85mm Use

W & P Products
Standard range
Order Code:

10-9550

Brand: W & P Products MPN: 153PF-002-1-50-00 EAN-13: 2050001574145
Qty Unit Price (Ex VAT)
1+ £0.438
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
34 in stock, despatched in 4 working days

The W & P Products SIL socket (precision) is manufactured by W & P Products and features a single row with two pins per row. It is designed for precision applications where reliable electrical connections are required. Typical applications include use in electronic assemblies and prototypes requiring durable and precise receptacles.
Case material Thermoplastic material
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector type Power strip, straight
Contact material Copper alloy
Contact surface Tin plated
CS 2.54mm
Dim (L x W x H) 9.80 x 5.08 x 2.54 mm
Dimensions L x B x H 5.08 x 2.54 x 9.8 mm
Factory colour Black
Height 2.54mm
Industrial packaging No
Length 9.80mm
Manufacturer part # 153PF-002-1-50-00
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute 153PF-002-1-50-00
No. of rows 1
Nominal current 3A
Nominal current - rounded value 3A
Pin length (PCB) 2.80mm
Pins per row 2
RoHS-compliant Yes
Separable No
Socket depth 6.10mm
Total number of pins 2
Type Receptacles (precision)
Width 5.08mm
