W & P Products 153-002-1-50-00 Precision Socket Connector 3A 1x2 Pins

Image Representative of Range

W & P Products 153-002-1-50-00 Precision Socket Connector 3A 1x2 Pins

W & P Products
Standard range
Order Code:

10-9546

Brand: W & P Products MPN: 153-002-1-50-00 EAN-13: 2050001143716
Qty Unit Price (Ex VAT)
1+ £0.199
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2,802 in stock, despatched in 4 working days

W & P Products manufactures the 153-002-1-50-00 precision socket connector, featuring 1 x 2 pins and supporting a nominal current of 3 A. This receptacle is designed for reliable electrical connections in precision instruments and electronic devices. It is commonly used in applications requiring durable and accurate socket connectors.
Case material Thermoplastic material
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector type Power strip, straight
Contact material Copper alloy
Contact surface Tin plated
CS 2.54mm
Dim (L x W x H) 10.00 x 5.08 x 2.54 mm
Factory colour Black
Height 2.54mm
Industrial packaging No
Insulation resistance
> 1010Ω
Length 10.00mm
Manufacturer part # 153-002-1-50-00
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute 1 153-002-1-50-00
Misc Attribute 2 Straight
No. of rows 1
Nominal current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage 150V AC
Pin length (PCB) 3mm
Pin length (receptacle) 2.40mm
Pin Ø 0.60mm
Pin shape Circular
Pins 1 x 2
Pins per row 2
RoHS-compliant Yes
Separable No
Socket depth 5.80mm
Temperature range -55 - +125°C
Total number of pins 2
Type Receptacles (precision)
Width 5.08mm
